Interactive EPA Rad Net Allows Near Real Time Radiation Samples, Including Charleston, WV

Edited by Tony Rutherford from Multiple Reports
EPA Measurment
EPA Measurment

CHARLESTON, WV (HNN) –

Although in service for awhile, the U.S. Environmental Protection Agency has a near “real time” network for radiation sampling located in a variety of cities across the United States. One of those is Charleston, WV.

The system has been developed for use by scientists, but it has been receiving interest from individuals desiring to educate and inform themselves about possible fallout from the crippled Japanese nuclear reactors.

Officially, EPA has declared radiation levels across the country as far below levels of concern; however, other experts have offered interpretations that , for instance, the data interpretation reveals in one case the normal exposure for a year

Japan recently acknowledged  that it did not release all the radiation it had it had on the first days following the earthquake.  That lead to  expert surfing leads and interpretation variance.

Still, the internet encourages interactivity and education.

Here’s the data taken in real time at about 2 a.m. April 13. After you scroll those readings, we’ll provide something that’s frustrating to find and use: The real time Rad Net link, including an FAQ page by the EPA for non-scientists interpreting the data.

Monitor Information:

Fixed Monitor Location: WV: CHARLESTON
Measurement Start Date/Time: 04/13/2011 03:10:33 AM
Measurement End Date/Time: 04/13/2011 04:10:41 AM
Beta Gross Count Rate (CPM): 28
Gamma Energy Range 2 Gross(CPM): 2282
Gamma Energy Range 3 Gross(CPM): 1467
Gamma Energy Range 4 Gross(CPM): 404
Gamma Energy Range 5 Gross(CPM): 245
Gamma Energy Range 6 Gross(CPM): 126
Gamma Energy Range 7 Gross(CPM): 150
Gamma Energy Range 8 Gross(CPM): 91
Gamma Energy Range 9 Gross(CPM): 42
Gamma Energy Range 10 Gross(CPM): 44

Note: Zero Values for "Beta CPM", "Gamma CPM" indicate data not available.

The site for the non-scientific public, displays graphs which are charted against Japanese earthquake before and after readings. http://www.epa.gov/japan2011/rert/radnet-charleston-bg.html

Monitor Information:

Fixed Monitor Location: OH: CINCINNATI
Measurement Start Date/Time: 04/13/2011 04:42:28 AM
Measurement End Date/Time: 04/13/2011 05:42:36 AM
Beta Gross Count Rate (CPM): 0
Gamma Energy Range 2 Gross(CPM): 1592
Gamma Energy Range 3 Gross(CPM): 945
Gamma Energy Range 4 Gross(CPM): 289
Gamma Energy Range 5 Gross(CPM): 133
Gamma Energy Range 6 Gross(CPM): 73
Gamma Energy Range 7 Gross(CPM): 80
Gamma Energy Range 8 Gross(CPM): 51
Gamma Energy Range 9 Gross(CPM): 29
Gamma Energy Range 10 Gross(CPM): 45

Monitor Information:

Fixed Monitor Location: KY: LOUISVILLE
Measurement Start Date/Time: 04/13/2011 04:17:09 AM
Measurement End Date/Time: 04/13/2011 05:17:17 AM
Beta Gross Count Rate (CPM): 67
Gamma Energy Range 2 Gross(CPM): 2645
Gamma Energy Range 3 Gross(CPM): 1746
Gamma Energy Range 4 Gross(CPM): 489
Gamma Energy Range 5 Gross(CPM): 284
Gamma Energy Range 6 Gross(CPM): 147
Gamma Energy Range 7 Gross(CPM): 179
Gamma Energy Range 8 Gross(CPM): 111
Gamma Energy Range 9 Gross(CPM): 49
Gamma Energy Range 10 Gross(CPM): 65

Monitor Information:

Fixed Monitor Location: ME: ORONO
Measurement Start Date/Time: 04/13/2011 04:04:46 AM
Measurement End Date/Time: 04/13/2011 05:04:54 AM
Beta Gross Count Rate (CPM): 10
Gamma Energy Range 2 Gross(CPM): 2303
Gamma Energy Range 3 Gross(CPM): 1341
Gamma Energy Range 4 Gross(CPM): 377
Gamma Energy Range 5 Gross(CPM): 183
Gamma Energy Range 6 Gross(CPM): 125
Gamma Energy Range 7 Gross(CPM): 134
Gamma Energy Range 8 Gross(CPM): 82
Gamma Energy Range 9 Gross(CPM): 28
Gamma Energy Range 10 Gross(CPM): 38

Monitor Information:

Fixed Monitor Location: TN: MEMPHIS
Measurement Start Date/Time: 04/13/2011 04:31:48 AM
Measurement End Date/Time: 04/13/2011 05:31:56 AM
Beta Gross Count Rate (CPM): 49
Gamma Energy Range 2 Gross(CPM): 2137
Gamma Energy Range 3 Gross(CPM): 1167
Gamma Energy Range 4 Gross(CPM): 335
Gamma Energy Range 5 Gross(CPM): 161
Gamma Energy Range 6 Gross(CPM): 104
Gamma Energy Range 7 Gross(CPM): 116
Gamma Energy Range 8 Gross(CPM): 69
Gamma Energy Range 9 Gross(CPM): 31
Gamma Energy Range 10 Gross(CPM): 40

Monitor Information:

Fixed Monitor Location: MO: ST. LOUIS
Measurement Start Date/Time: 04/13/2011 03:32:09 AM
Measurement End Date/Time: 04/13/2011 04:32:16 AM
Beta Gross Count Rate (CPM): 14
Gamma Energy Range 2 Gross(CPM): 1706
Gamma Energy Range 3 Gross(CPM): 990
Gamma Energy Range 4 Gross(CPM): 273
Gamma Energy Range 5 Gross(CPM): 141
Gamma Energy Range 6 Gross(CPM): 74
Gamma Energy Range 7 Gross(CPM): 91
Gamma Energy Range 8 Gross(CPM): 57
Gamma Energy Range 9 Gross(CPM): 27
Gamma Energy Range 10 Gross(CPM): 28

Monitor Information:

Fixed Monitor Location: OR: CORVALLIS
Measurement Start Date/Time: 04/13/2011 03:21:24 AM
Measurement End Date/Time: 04/13/2011 04:21:33 AM
Beta Gross Count Rate (CPM): 21
Gamma Energy Range 2 Gross(CPM): 1794
Gamma Energy Range 3 Gross(CPM): 972
Gamma Energy Range 4 Gross(CPM): 274
Gamma Energy Range 5 Gross(CPM): 144
Gamma Energy Range 6 Gross(CPM): 94
Gamma Energy Range 7 Gross(CPM): 107
Gamma Energy Range 8 Gross(CPM): 76
Gamma Energy Range 9 Gross(CPM): 27
Gamma Energy Range 10 Gross(CPM): 36

Monitor Information:

Fixed Monitor Location: AZ: TUCSON
Measurement Start Date/Time: 04/13/2011 03:16:32 AM
Measurement End Date/Time: 04/13/2011 04:16:39 AM
Beta Gross Count Rate (CPM): 44
Gamma Energy Range 2 Gross(CPM): 3215
Gamma Energy Range 3 Gross(CPM): 1779
Gamma Energy Range 4 Gross(CPM): 485
Gamma Energy Range 5 Gross(CPM): 243
Gamma Energy Range 6 Gross(CPM): 154
Gamma Energy Range 7 Gross(CPM): 175
Gamma Energy Range 8 Gross(CPM): 111
Gamma Energy Range 9 Gross(CPM): 39
Gamma Energy Range 10 Gross(CPM): 49

Monitor Information:

Fixed Monitor Location: NV: LAS VEGAS
Measurement Start Date/Time: 04/13/2011 02:50:03 AM
Measurement End Date/Time: 04/13/2011 03:50:11 AM
Beta Gross Count Rate (CPM): 86
Gamma Energy Range 2 Gross(CPM): 2359
Gamma Energy Range 3 Gross(CPM): 1409
Gamma Energy Range 4 Gross(CPM): 408
Gamma Energy Range 5 Gross(CPM): 233
Gamma Energy Range 6 Gross(CPM): 142
Gamma Energy Range 7 Gross(CPM): 166
Gamma Energy Range 8 Gross(CPM): 111
Gamma Energy Range 9 Gross(CPM): 41
Gamma Energy Range 10 Gross(CPM): 48

Monitor Information:

Fixed Monitor Location: CA: ANAHEIM
Measurement Start Date/Time: 04/13/2011 03:29:24 AM
Measurement End Date/Time: 04/13/2011 04:29:32 AM
Beta Gross Count Rate (CPM): 39
Gamma Energy Range 2 Gross(CPM): 2774
Gamma Energy Range 3 Gross(CPM): 1676
Gamma Energy Range 4 Gross(CPM): 497
Gamma Energy Range 5 Gross(CPM): 255
Gamma Energy Range 6 Gross(CPM): 177
Gamma Energy Range 7 Gross(CPM): 194
Gamma Energy Range 8 Gross(CPM): 122
Gamma Energy Range 9 Gross(CPM): 38
Gamma Energy Range 10 Gross(CPM): 48

Monitor Information:

Fixed Monitor Location: WA: OLYMPIA
Measurement Start Date/Time: 04/12/2011 04:53:09 PM
Measurement End Date/Time: 04/12/2011 05:53:17 PM
Beta Gross Count Rate (CPM): 26
Gamma Energy Range 2 Gross(CPM): 1254
Gamma Energy Range 3 Gross(CPM): 649
Gamma Energy Range 4 Gross(CPM): 197
Gamma Energy Range 5 Gross(CPM): 93
Gamma Energy Range 6 Gross(CPM): 58
Gamma Energy Range 7 Gross(CPM): 74
Gamma Energy Range 8 Gross(CPM): 36
Gamma Energy Range 9 Gross(CPM): 22
Gamma Energy Range 10 Gross(CPM): 32



OK, now here’s where you can DIY: https://cdxnode64.epa.gov/radnet-public/showMap.do

Here’s the data for the public site. It shows levels BEFORE and AFTER the accident. http://www.epa.gov/japan2011. And, Reno, Nevada., provides data for accessing more detailed near real time information. http://www.epa.gov/japan2011/rert/radnet-reno-bg.html
